LD Systems MAUI 11 G3 MIX Portable 2060W Powered Column PA System (White)

LD Systems Maui 11 G3 Mix Overview

Perform at your best with the LD Systems MAUI 11 G3 MIX, an all-in-one compact column array with an integrated 6-input, 4-channel mixer, well suited for concerts, mobile DJs, or as a public-address system at weddings, corporate events, and more. The MAUI 11 G3 MIX delivers a powerful and precise sound, thanks to the 730W RMS power (1460W peak) Class-D amplifier that's housed in the dual 8" subwoofer module. The columns are equipped with six 3.5" midrange drivers and two 1" tweeters, providing an even sound distribution with constant horizontal dispersion in combination with the innovative phase plug design. Additionally, the curved waveguide ahead of the tweeters carries the high frequencies evenly to the very rear audience areas.

The LD Systems engineers fine-tuned the system to reduce harmonic distortion and interference and make the sound more transparent, vibrant, and powerful, resulting in a highly precise reproduction of vocals and instruments across the entire 120 x 30° dispersion field. The MAUI 11 G3 MIX is capable of cardioid subwoofer operation with the use of an additional subwoofer (separately sold). Simply press the Cardioid button to enable the onboard DSP's cardioid mode, which can lower the rear volume up to 18 dB. In addition, the ultradurable polyurea coating of the subwoofer easily withstands the toughest demands on the road.

Benefits

• 1460W peak-power and 125 dB max SPL

• Powerful bass reproduction with 2 x 8" subwoofers

• Balanced mids thanks to 6 x 3.5" full-range speakers

• Precise and silky highs with 2 x 1" high-frequency drivers

• Digital 6-channel mixer with onboard effects and footswitch input

• Free App with Easy and Expert mode for remote adjustments via smartphone and tablet (optional)

• SysLink for connecting two MAUI G3 MIX to double the mixer channels

• Cardioid column for controlled low-mid and midrange sound dispersion

Additional Features

• BEM optimized HF waveguide and midrange phase plugs for homogeneous dispersion

• Optimized bass-reflex design improves bass response and reduces air flow noise

• Can be combined with an additional MAUI 11 G3 subwoofer for increased low end or for cardioid subwoofer setups

• Dynx DSP (Gen. 2) for distortion-free sound even at maximum volume

• Wireless streaming via Bluetooth

• Automatic setup detection for quick and easy operation

• Fast and simple assembly without stands or cables

• Rugged birch plywood subwoofer housing with durable polyurea-coating

• Lightweight, powder coated aluminum column housing

MAUI G3 Mix

With the MAUI G3 Mix versions, you no longer need a mixing console. The digital 6-channel mixer offers a variety of options, thanks to mic / Hi-Z / line inputs. This means you can directly connect and mix and filter signals from microphones, guitars, basses, keyboards, or various players. By connecting two MAUI G3 MIX systems via SysLink to create a stereo setup, you double the number of available analog inputs. Direct streaming via Bluetooth 5.0 is available.
Menu control is extremely intuitive through the user panel with LC display and three rotary-push controls. With a few simple steps, you can adjust effects, EQ, dynamics, and monitor signals, even for each individual channel.

Mix App

Bring all the settings you can make on the MAUI G3 MIX to your smartphone or tablet. With the user-friendly display of the MAUI G3 MIX app, you always have your mix under control.
The Easy Mode is ideal for a quick start: with presets and simple adjustment options, you can get started right away. For those who want to delve deeper into their sound, the Expert Mode offers advanced functions, from detailed filtering to precise control of attack and compressor for each channel.

Room Filling Sound

Superwide 120° horizontal dispersion
Thanks to the line-array arrangement and integrated waveguides on top of the low-mid speakers (also called phase plugs), MAUI G3 offers a superwide 120° of constant horizontal dispersion.
Narrow and precise vertical dispersion

The sophisticated curved waveguide offers a narrow and precise vertical dispersion of 30°. This ensures that the high frequencies will reach the front row of your audience just as effectively as the very back of the venue.

Main and Follower Subwoofer

+6 dB low end
Simply place the follower subwoofer next to your main system facing front to enhance the bass response of +6 dB towards the audience.
Cardioid setup

If you are looking to build a cardioid subwoofer setup, simply rotate the subwoofer 180°, and activate the cardioid option on the back of the sub.
Automatic column detection

With the automatic column detection, the subwoofer automatically enables the follower mode when the column is removed and adapts the DSP settings accordingly.

Cardioid Column

Passive cardioid column
The 2-piece passive column of MAUI G3 has been reworked entirely and refined in many aspects. A unique feature of the new column is its passive cardioid design offering controlled low-mid and midrange sound dispersion.
-18 dB to the rear

Thanks to its exclusive design, the column offers real cardioid dispersion characteristics and provides an 18 dB attenuation to the rear between 100 Hz and 1 kHz.
Acoustic dampening foam

The cardioid behavior of the column is made possible by a clever use of acoustic dampening foam behind the tweeters and mid woofers within the column itself and by precise cutouts within the column aluminum housing.

Cardioid Sub Setup

Craft your best sound
With an additional subwoofer, you can create a cardioid setup. Simply rotate the follower subwoofer 180°, and activate the cardioid setup on the back of the sub.
-15 dB low-end to the rear

With -15 dB bass attenuation to the rear, you reduce the risks of feedback, hearing fatigue, and phase cancellations significantly.
Up to 3 dB additional low-end to the front

The cardioid setup has a nice side effect of enhancing the low-end response 2 to 3 dB towards the audience—more bass where you need it, and not anywhere else.
